MRC H403/Steel/C3/ABEC-1 Bearing 201SZZ

Home > MACHINERY & CONSTRUCTION > POWER TRANSMISSION >

Alternative Views:

OUR PRICE: $7.35

Quantity in Stock:16

Availability:: Usually Ships in 1 to 2 Business Days
Product Code: L002059

Qty:

Description

Technical Specs

Extended Information

This is a MRC H403/Steel/C3/ABEC-1 Bearing 201SZZ that is new old stock with original packaging.

Manufacturer:	MRC Bearing Service
Weight:	0.096 lbs.
Product Name:	200-S Light Series Ball Bearing
Description:	12 mm ID x 32 mm OD x 10 mm Wide; Double Sealed; No Snap Ring; Single Row Radial Steel Bearing

Specifications
Inch/Metric	Metric Bore	Bore Type	Round Bore
I.D.	12 mm	O.D. [Min]
O.D. [Max]		O.D.	32 mm
Width [Min]		Width [Max]
Width	10 mm	Enclosure	Double Sealed
Rows of Balls	Single	Material	Steel
O.D. Type	Straight	Bearing Type	Radial
Precision	Standard	Radial Internal Clearance Specification	Normal Clearance
Ambient Temperature Range [Min]		Ambient Temperature Range [Max]
Ball Material	Steel	Cage Type	Metal
Capacity	Standard Capacity	Contact Angle	0°
Guide Type		Lubrication
Outer Ring Width	10 mm	Precision Level	Standard (ABEC 1)
Preload Level	None	Seal Material	Rubber
Seal Type	Contact Seals	Seal Width
Dynamic Load Rating	1550 lbf	Static Load Rating [Max]	697 lbf
Ball Dia.		Bearing Design
Bore B		Cage Material	Steel
Collar No.		Collar O.D.
Collar Width		Corner Radius [Min]
Eccentric Collar Offset		Fillet Radius	0.64 mm
Flange O.D. [Max]		Flange O.D.
Flange Width [Max]		Flange Width
Flush Ground		Housing Shoulder Diameter [Min]
Housing Shoulder Diameter [Max]		Housing Shoulder Diameter
Industry Standard Part #		Inner Ring O.D.
Inner Ring Offset		Inner Ring Width	10 mm
Internal Design		Limiting Speed
Limiting Speed - Grease	22000 rpm	Limiting Speed - Oil	28000 rpm
Limiting Speed - Sealed	15000 rpm	Locking Device	No Locking Device
Lube Hole Center		Lubricant	Polyurea Base
Misalignment Range		No. in Set	Single Bearing
No. of Balls		O.D. (B)
Outer Ring		Outer Ring Inner Diameter
Outer Ring Size		Peak Running Torque (mg-mm)
Peak Starting Torque (mg-mm)		Pre Lubricant
Preload Amount		Radial Internal Clearance	Normal
Radial Load Rating [Max]		Radial Rigidity (lbf/µm)
Reference Speed		Seal O.D.
Seal Protection Width		Seating Washer
Series		Set Screw Offset
Set Screw Size		Shaft Shoulder Diameter [Min]
Shaft Tolerance		Snap Ring	No Snap Ring
Snap Ring O.D.		Snap Ring Offset
Snap Ring Thickness		Special Features
Stamping		Static Thrust Load Rating [Max]
Temperature Range [Min]	-22 °F	Temperature Range [Max]	250 °F
Use With
